CARBURETOR/FUEL PUMP
90-826883R2 JUNE 1998 Page 3A-5
Carburetor (Seapro/Marathon 15/25 & Super 15)
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 CARBURETOR (WMC-54)
1 1 CARBURETOR (WMC-46A)
1 CARBURETOR (WMC-56)
1 THROTTLE VALVE (WMC–46/46A/54/54A)
1 THROTTLE VALVE (WMC-56/56A)
3 1 THROTTLE SHAFT
4 1 FUEL BOWL
5 1 FLOAT
6 1 VALVE–inlet needle
1 JET–main fuel (.076) (WMC–46)
7 1 JET–main fuel (.080) (WMC–46A/54/54A)
1 JET–main fuel (.046) (WMC–56/56A)
8 1 PLUG–jet retainer 32 3.6
9 1 CHOKE SHAFT
10 1 CHOKE LEVER
11 1 BODY–fuel pump
12 5 SCREW–fuel pump cover 18 2.0
13 1 COVER–pump (WMC-54/54A/56/56A)
14 1 COVER–fuel pump (WMC-46/46A)
15 1 CHOKE VALVE
16 1 GASKET/DIAPHRAGM KIT
17 1 REPAIR PARTS KIT
18 1 PLATE–cover
19 1 SCREW–bowl drain 14 1.6
20 2 SCREW–cover plate 18 2.0
21 1 GASKET–carburetor
22 1 DIAPHRAGM/GASKET
23 1 GASKET
24 1 FLOAT PIN
25 1 FLOAT LEVER
26 1 CHOKE LINK
27 1 SCREW
28 1 NUT
