POWERHEAD
Page 4-6 90-826883R2 JUNE 1998
Cylinder Block and Covers
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 CYLINDER BLOCK
2 1 STUD (M6x1x32) Drive Tight
3 2 ELBOW (45 deg.)
4 1 STUD (M6x1x50) (Commercial) Drive Tight
5 1 DOWEL PIN
6 5 SCREW (60 MM) 360 30 40.7
7 1 STUD (M6x1x32) Drive Tight
8 2 STUD Drive Tight
9 1 SCREW
10 1 NUT
11 1 GASKET
12 1 REED BLOCK
13 1 GASKET
14 1 PLATE--carb adaptor
15 2 CHECK VALVE
16 3 SCREW (M5x.8x20) 80 9.0
17 2 TUBING (13-1/4 IN.)
18 2 O-RING
19 2 COVER
20 4 SCREW (M5x.8x16) 40 4.5
21 1 BALL--threaded 40 4.5
22 6 SCREW (M5x.8x16) 40 4.5
23 2 COVER
24 2 O-RING
25 1 GASKET
26 1 COVER CASTING
27 1 COVER ASSEMBLY
28 1 PIPE PLUG (BRASS) Drive Tight
29 5 SCREW (30 MM) 140 12.0 15.8
30 1 FITTING
31 1 HOSE--tell tale (8 IN.)
32 1 ELBOW Drive Tight
33 2 SCREW (M6x1x40) 140 12.0 15.8
34 1 COVER
35 1 GASKET
36 1 GASKET
37 1 THERMOSTAT
38 1 PLUG--serial number Stake Tight
39 2 O-RING
40 2 COVER
41 1 STRAP
42 4 SCREW (M5x.8x16) 40 4.5
43 1 GASKET--exhaust manifold
44 1 EXHAUST MANIFOLD
45 1 GASKET--exhaust manifold cover
46 1 COVER--exhaust manifold
47 9 SCREW (M6 x 1 x 40) 140 12.0 15.8
