POWERHEAD
Page 4-14 90-826883R2 JUNE 1998
7. Remove 9 bolts and separate exhaust cover and exhaust manifold from cylinder
block.
c
b
a
57084
a - Bolts (9)
b - Exhaust Cover
c - Exhaust Manifold
NOTE: If engine is suspected of having been overheated or spark plugs are grayish col-
ored(asignofpossiblewaterintrusion),inspectexhaustmanifoldforwarpageorforprop-
erplacement andintegrityof gasketswhichwill allowwaterto entercylindersthroughex-
haust ports.
8. Remove 10 bolts and 4 transfer covers -- Starboard Side
57083
a
a - Transfer Covers
To Next Page
