CLAMP AND SWIVEL BRACKET
90-826883R2 JUNE 1998 Page 5-3
Clamp Bracket Assembly
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 CLAMP BRACKET (STBD.) (BLACK)
1
1 CLAMP BRACKET (STBD.) (GRAY)
1
1 CLAMP BRACKET (STBD.) (TRACKER GRAPHITE GRAY)
1 CLAMP BRACKET (PORT) (BLACK)
2
1 CLAMP BRACKET (PORT) (GRAY)
2
1 CLAMP BRACKET (PORT) (TRACKER GRAPHITE GRAY)
3 2 THUMB SCREW ASSEMBLY
4 2 RIVET
5 2 HANDLE
6 2 SCREW--washer attaching 140 12.0 15.8
7 2 WASHER--thumb screw
8 1 NUT (1/4-28) 65 7.3
9 1 NUT (7/8-14) 120 10.0 13.6
10 1 SCREW (M6x1x40) 140 12.0 15.8
11 1 HANDLE--carrying
12 1 SPACER
13 1 WASHER--tilt tube (NYLON)
14 1 TILT TUBE
15 1 WASHER--tilt tube (NYLON)
16 1 DECAL--co-pilot
17 1 TILT PIN ASSEMBLY
18 1 SPRING
19 1 SCREW (M6x1x40) 140 12.0 15.8
20 1 NUT (7/8-14) 120 10.0 13.6
21 1 CLIP--safety
22 2 BOLT--clamp bracket to transom
23 2 WASHER--clamp bracket bolt
24 2 NUT--clamp bracket bolt
25 1 NUT (1/4-28) 65 7.3
26 1 SCREW (1/4-28x1 IN.) 65 7.3
27 1 LEVER--tilt stop - starboard side
28 1 NUT (1/4-28) 65 7.3
29 1 SPRING--tilt stop lever screw
30 1 SCREW (1/4-28x1-3/4 IN.) 65 7.3
31 1 SCREW (1/4-28x1-3/4 IN.) 65 7.3
32 1 WAVE WASHER--tilt stop strap screw
33 1 NUT (1/4-28) 65 7.3
34 1 STRAP--tilt stop - port side
35 1 SCREW (1/4-28x1 IN.) 65 7.3
