CLAMP AND SWIVEL BRACKET
90-826883R2 JUNE 1998 Page 5-5
Swivel Bracket Assembly
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 ROD--reverse hook
2 1 NUT 125 14.1
3 1 HANDLE
4 1 WASHER
5 1 BRAKE PLATE
6 1 BRAKE DISC
7 1 SWIVEL HEAD PLATE (Included W/Ref. #36)
8 1 BRAKE DISC
9 2 SCREW (M6x1x14) (Included W/Ref. #36) 140 12.0 15.8
10 1 ROD
11 1 SWIVEL BRACKET
12 1 GREASE FITTING 35 4.0
13 2 GREASE FITTING 35 4.0
14 1 GREASE FITTING 35 4.0
15 1 BUSHING KIT
16 1 O-RING
17 1 BUSHING
18 1 BUSHING
19 1 WASHER
20 1 HOOK ASSEMBLY--reverse lock
2
1
1 SPRING (REMOTE CONTROL MODELS)
22 1 SPRING (ALL OTHER MODELS)
23 1 SPRING
24 1 RING--retaining
25 1 PIN
26 1 TROLL BRACKET
27 1 SPRING
28 1 LEVER--control
29 1 RING--retaining
30 2 COVER--lower mount
31 2 SCREW (M8x100) 390 32.5 44.1
32 1 SCREW (M8x60) 390 32.5 44.1
33 3 WASHER
34 3 NUT 390 32.5 44.1
35 1 BUMPER--front
36 2 MOUNT--lower
37 1 SWIVEL HEAD
38 2 SCREW--upper mount (M8x1.25x133) 220 18.0 24.9
39 2 MOUNT--upper
40 2 WASHER--rubber - upper mount screw
41 2 WASHER--upper mount screw
42 2 NUT--upper mount screw 220 18.0 24.9
43 1 SCREW (.375-24x1.25) 240 20.0 27.1
44 1 STEERING LINK ASSEMBLY
45 1 WASHER
46 1 NUT
1 BRACKET--ride guide (BLACK)
47 2 SCREW (M10x1.5x25) 390 32.5 44.1
48 2 LOCKWASHER
49 1 WASHER
50 1 NUT 240 20.0 27.1
