Page #223 background image
GEAR HOUSING
90-826883R2 JUNE 1998 Page 6A-7
Gear Housing (Drive Shaft)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 GEAR HOUSING ASSEMBLY
2 1 SLEEVE
3 2 SEAL--gear housing
4 1 ROLLER BEARING--upper
5 2 DOWEL PIN (.187 x .53)
6 1 SCREW (.375 x.25) 60 6.8
7 1 WASHER--sealing
8 1 SCREEN--water inlet-port
9 1 SCREW (M5 x 40) 25 2.8
10 1 DRAIN SCREW--magnetic 60 6.8
11 1 WASHER
12 1 SCREEN--starboard
13 1 NUT (M5)
14 1 ROLLER BEARING ASSEMBLY
15 1 CUP
16 1 PINION GEAR (12-29)
17 1 NUT 15 20.3
18 1 GASKET
19 1 FACE PLATE
20 1 WASHER
21 1 KEY
22 1 lMPELLER
23 1 WASHER
24 1 O-RING
25 1 WATER PUMP ASSEMBLY
26 1 INSERT
27 1 SEAL
28 1 RING
29 4 BOLT (M6 x 16) 60 6.8
30 1 SHIFT SHAFT
31 1 NUT (M6) Tighten Securely
32 1 COUPLER Tighten Securely
33 1 SHIFT SHAFT (UPPER)
34 1 DRIVE SHAFT
35 1 BOOT
36 1 RETAINER
37 1 O-RING
38 1 O-RING
39 1 WASHER
40 1 SPRING
41 1 WASHER
42 1 ROLL PIN
43 1 SHIFT CAM
44 1 DRIVE PIN
