GEAR HOUSING
90-826883R2 JUNE 1998 Page 6A-9
Gear Housing (Propeller Shaft)
TORQUE
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 GEAR HOUSING ASSEMBLY
45 1 TRIM TAB
46 1 BOLT (M8x30) 17.1 23.2
47 1 WASHER
48 1 TAPERED ROLLER BEARING
49 1 CUP
50 1 FORWARD GEAR (12-29)
51 1 BUSHING
52 1 CAM FOLLOWER
53 1 SPRING
54 1 CLUTCH
55 1 CROSS PIN
56 1 SPRING
57 1 PROPELLER SHAFT
58 1 REVERSE GEAR (12-29)
59 1 BEARING CARRIER ASSEMBLY 80.0 108.5
60 1 ROLLER BEARING
61 1 OIL SEAL (INNER)
62 1 OIL SEAL (OUTER)
63 1 O-RING
64 1 PLATE
65 3 BOLT (M5x16) 65 7.2
66 4 BOLT (M10 x 35) 40 54.2
67 4 WASHER
68 1 THRUST HUB ASSEMBLY
69 1 PROPELLER
70 1 PROP NUT 16.7 22.6
