JET DRIVE
90-826883R2 JUNE 1998 Page 6B-3
Jet Pump Assembly (S/N 0G157845 & Below)
TORQUE
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
-- 1 JET PUMP ASSEMBLY (BLACK)
-- 1 JET PUMP ASSEMBLY (GRAY)
1 1 HOUSING--pump
2 1 HOSE--lube
3 1 IMPELLER
4 1 HOUSING--intake
5 1 LINER
6 1 DRIVESHAFT
7 1 SLEEVE
8 1 NUT
9 1 ADAPTOR
10 1 BASE--pump
11 4 SCREW (10-32 x 1) 35 4.0
12 1 SCREW (.375-16 x 1-1/4) 23.0 31.2
13 4 SCREW (.312-18 x 2) 160 13.0 18.1
14 4 SCREW
15 1 KEY--impeller
16 8 SHIM--impeller
17 1 TAB WASHER
18 6 SCREW (.250-20 x 3/4) 96 8.0 10.8
19 2 SCREW (10-24 x 5/8) 30 3.4
