Mercury 15XD User Manual

JET DRIVE
90-826883R2 JUNE 1998 Page 6B-9
Jet Linkage (S/N 0G157846 & Up)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 NUT
2 1 LOCKWASHER
3
1 SHIFT HANDLE (Use without Ref. #4)
3
1 SHIFT HANDLE (Use with Ref. #4)
4 1 SPACER--sleeve
5 1 ROD END
6 2 SPRING
7 2 WASHER
8 2 COTTER PIN
9 2 NUT 70 5.8 7.9
10 1 SHIFT LEVER
11 1 SCREW (10-32 x 3/4)
12 1 SCREW (10-32 x 2-1/2) 30 2.5 3.4
13 1 SHIFT ROD
14 1 ROD END
15 1 TILT LATCH ROD
