THROTTLE/SHIFT LINKAGE
90-826883R2 JUNE 1998 Page 7A-3
Throttle and Shift Linkage (Tiller Handle Shift)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SWITCH--interlock
2 2 SCREW (M3.5x0.6x16 hex wsh) 20.0 2.3
3 1 LINK interlock
4 1 LEVER--interlock control
5 1 SCREW (M6x1x25 hex hd cap) 120 13.6
6 1 PLAIN WASHER (62x.255x.03)
7 1 BUSHING
8 1 LEVER--backplate
9 1 LEVER--horizontal shift shaft (PORT)
10 1 SHIFT SHAFT (HORIZONTAL)
11 1 SHIFT LINK ASSEMBLY
12 1 SOCKET
13 1 NUT
14 1 THROTTLE LINK ASSEMBLY
15 2 SOCKET
16 1 NUT
17 1 LINK--spark adjustment S/N
18 2
SOCKET USA--0G437999 & BELOW
19 1 NUT BEL-- 9926999 & BELOW
20 1 THROTTLE CAM ASSEMBLY S/#
21 1 LEVER--gear shift USA--0G286099 & BELOW
22 1 PRIMARY LEVER BEL--9881099 & BELOW
23 1 WASHER (.62x.255x.03) (Use w/Ref #20)
20 1 THROTTLE CAM ASSEMBLY S/N
21 1 LEVER--gear shift USA--0G286100 thru 0G437999
22 1 PRIMARY LEVER BEL--9881100 thru 9926999
23 1 WASHER (Use w/Ref #20)
24 1 WASHER
25 1 WAVE WASHER
26 1 THROTTLE CAM S/N
27 1 SPRING USA-0G438000 & UP
28 1 SPARK ARM BEL-9927000 & UP
29 1 TIMING LINK
30 1 SECONDARY GEAR
31 1 PRIMARY GEAR
32 1 BUSHING
33 1 BALL--detent
34 1 SPRING
35 1 SCREW (M6x1x20 hex hd cap) 120 13.6
36 1 SCREW (M6x1x25 hex hd cap) 120 13.6
37 1 BUSHING
38 1 WASHER (.62x.255x.03)
39 1 SCREW (M6x1x30) 120 13.6
40 1 WASHER (.62x.255x.03)
41 1 BUSHING
42 1 CONTROL PLATFORM
43 3 SCREW (M5x1x16 hex washer hd) 120 13.6
44 1 PLATE
45 1 STRAP
46 1 SCREW
