GENERAL INFORMATION
Page 1C-8 90-826883R2 JUNE 1998
5. Coat the propeller shaft with Quicksilver Anti-Corrosion Grease or 2-4-C Marine Lu-
bricant with Teflon.
IMPORTANT: To prevent the propeller hub from corroding and seizing to the pro-
peller shaft, especially in salt water, always apply a coat of the recommended lubri-
cant to the entire propeller shaft at the recommended maintenance intervals and
also each time the propeller is removed.
6. Flo-Torque I Drive Hub Propellers
– Install forward thrust hub, propeller, rear thrust
hub and propeller nut onto the shaft.
a
b
c
d
a - Forward Thrust Hub
b - Propeller
c - Rear Thrust Hub
d - Propeller Nut
7. Flo-Torque II Drive Hub Propellers – Install forward thrust hub, replaceable drive
sleeve propeller, rear thrust hub and propeller nut onto the shaft.
a
b
c
d
e
a - Forward Thrust Hub
b - Replaceable Drive Sleeve
c - Propeller
d - Rear Thrust Hub
e - Propeller Nut
