TILLER HANDLE
90-826883R2 JUNE 1998 Page 7B-3
Tiller Handle Assembly
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
-- 1 TILLER HANDLE (BLACK) TILLER HANDLE
-- 1
TILLER HANDLE (GRAY) SHIFT
-- 1 TILLER HANDLE (BLACK) SIDE SHIFT
-- 1 TILLER HANDLE (GRAY)
1
1 COVER KIT (TILLER HANDLE SHIFT)
1
1 COVER KIT (SIDE SHIFT)
2 1 PULLEY
3 1 CASE
4 1 SCREW (#10-16x1/2 IN.) Drive Tight
5
1 THROTTLE CABLE (TILLER HANDLE SHIFT)
5
1 THROTTLE CABLE (SIDE SHIFT)
6
1 THROTTLE CABLE (TILLER HANDLE SHIFT)
6
1 THROTTLE CABLE (SIDE SHIFT)
7 1 SLEEVE--throttle cable
8
1 ARM--steering handle (BLACK)
8
1 ARM--steering handle (GRAY)
9
2 SCREW (M5x1x16) 80 9.0
9
2 SCREW (M6x1x20)
10 1 SCREW (M5x.5x16) 50 5.6
11 1 KNOB--throttle friction As Required
12 1 SPRING
13 1 LOCK--throttle friction
14 1 SCREW (M6x1x25)
15 1 TILLER TUBE
1
6
1 DECAL (TILLER HANDLE SHIFT)
1
6
1 DECAL (SIDE SHIFT)
1
7
1 THROTTLE HANDLE (TILLER HANDLE SHIFT)
1
7
1 THROTTLE HANDLE (SIDE SHIFT)
18 1 GRIP--throttle handle
19 1 STOP SWITCH
20 1 RETAINER
2
1
1 PLATE--tiller handle (Use with 6MM screw REF. #9)
2
1
1 PLATE--tiller handle (Use with 5MM screw REF. #9)
22 1 BUSHING
23 2 SCREW (M10x1.5x80) 390 32.5 44.1
2
4
1 BRACKET (BLACK)
2
4
1 BRACKET (GRAY)
25 1 BUSHING
26 1 WASHER
27 1 WAVE WASHER
28 1 WASHER
29 1 WASHER
