TILLER HANDLE
90-826883R2 JUNE 1998 Page 7B-5
5. Remove nut securing access cover and remove cover
57035
a
b
a - Nut
b - Access Cover
6. Disconnect stop button wires -- BLACK/YELLOW and BLACK.
57036
a
b
a - BLACK/YELLOW
b - BLACK
