Mercury 15XD User Manual

SIDE SHIFT
90-826883R2 JUNE 1998 Page 7C-3
Throttle and Shift Linkage (Side Shift)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 LINK--interlock
2
1 LEVER (20/25) (JET 20 - S/N-G157846 & UP)
2
1 LEVER (JET 20 - S/N-G157845 & BELOW)
3 1 SCREW (M6x1x25) 120 13.6
4 1 WASHER
5 1 BUSHING
6 1 LEVER--backplate
7 1
SPRING--detent NOT USED ON JET 20
8 1 SPRING PLATE S/N G157845 & BELOW
9 2 SCREW (M5x0.8x16) 40 4.5
10 1 LEVER--horizontal shift shaft (PORT)
11 1 SHIFT SHAFT (HORIZONTAL)
12 1 SHIFT HANDLE
13 1 SCREW (M5 x 20) 50 5.6
14 1 WASHER
15 1 THROTTLE CAM
16 1 WASHER
17 1 SPARK ADJUST LINK 20 JET
18 2 SOCKET
19 1 NUT
20 1 ANCHOR BRACKET--cable
15 1 THROTTLE CAM 20/25
16 1 WASHER
17 1 SPARK ADJUST LINK S/N
18 2 SOCKET USA-0G437999 & BELOW
19 1 NUT BEL-9926999 & BELOW
2
0
1 ANCHOR BRACKET--cable
2
0
1 ANCHOR BRACKET--cable
21 1 WASHER
22 1 WAVE WASHER
23 1 THROTTLE CAM 20/25 S/N
24 1 SPRING USA-0G438000 & UP
25 SPARK ARM BEL-9927000 & UP
26 TIMING LINK
27 1 SCREW (M6x1x 25) 120 13.6
28 1 BUSHING
29 3 SCREW (M5x1x16) 120 13.6
