SIDE SHIFT
90-826883R2 JUNE 1998 Page 7C-7
3. Connect throttle cables to throttle cam and throttle cable anchor bracket as outlined
in “Throttle Cable” -- “Installation”, preceding.
57063
a
c
b
a - Throttle Cables
b - Throttle Cam
c - Bracket
