MANUAL STARTER
90-826883R2 JUNE 1998 Page 8-1
OUTBOARD MOTOR INSTALLATION/ATTACHMENTS
Section 8 - Manual Starter
Table of Contents
Specifications 8-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starter Assembly (Manual) 8-2. . . . . . . . . . . . . . . . . . .
Rewind Starter Assembly 8-4.. . . . . . . . . . . . . . . . . . .
Removal 8-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starter Rope Replacement 8-7. . . . . . . . . . . . . . . . . . .
Disassembly 8-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning and Inspection 8-12. . . . . . . . . . . . . . . . . . . .
Reassembly 8-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications
STARTING
SYSTEM
Manual Start
Rope Length
Recoil
66 in. (1676 mm)
