IGNITION
90-826883 R2 JUNE 1998 Page 2A-5
Ignition/Electrical Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 COVER--ignition coil
2 3 SCREW--ignition coil cover (M5x.8x55) 80 9.0
1
STATOR ASSEMBLY (20/25--USA-S/N-0G437999 & BELOW)
(BEL-S/N-9926999 & BELOW)
3
1
STATOR ASSEMBLY (20/25--USA-S/N-0G438000 & UP)
(BEL-S/N-9927000 & UP)
1 STATOR ASSEMBLY (JET 20)
4 2 SCREW--stator attaching (M5x.8x25) 80 9.0
5 1 SCREW--stator attaching (M5x12) 80 9.0
6 1 CLIP
7 1 SCREW--clip to crankcase (#10-16x1/2 IN.) Drive Tight
8 1 C-WASHER--clip screw
1 SWITCH BOX (JET 20)(S# USA-0G590000 & UP)
9
1 SWITCH BOX (JET 20)(S#USA-0G589999 & BELOW)
9
1
SWITCH BOX (20/25--USA-S/N-0G437999 & BELOW)
BEL-S/N-9926999 & BELOW)
1
0
1
SWITCH BOX (20/25--USA-S/N-0G438000 thru 0G589999)
(BEL-S/N-9927000 thru 9973099)
1
0
1
SWITCH BOX (20/25--USA-S/N-0G590000 & UP)
(BEL-S/N-9973100 & UP)
11 2 SCREW (M5 x 20)
12 3 SCREW (M5x.8x35 hex washer head) Drive Tight
13 1 SCREW--ground wire Drive Tight
14 1 CLIP
15 1 TRIGGER ASSEMBLY
16 1 TERMINAL BLOCK
17 2
SCREW--terminal block (#10-16x5/8 IN.) COMMERCIAL
18 2 SCREW--terminal block (#10-16x3/8 IN.)
19 1 STATOR ASSEMBLY--auxiliary
20 3 SCREW (M5x.8x30 hex head) 80 9.0
21 AR STA-STRAP
2
2
2 SPARK PLUG (NGK #BP8H-N-10) 240 20 27.1
2
2
2 SPARK PLUG (NGK #BPZ8H-N-10) (CAN/BELG.) 20 27.1
23 1 HI-TENSION CABLE SET
24 1 HI-TENSION CABLE (Part of Ref. #22)
25 2 BOOT ASSEMBLY--spark plug
26 AR STA-STRAP
27 2 IGNITION COIL ASSEMBLY
28 4 NUT--coil terminal (1#10-32 Brass) 25 2.8
29 2 CABLE ASSEMBLY (Black)
