SPECIFICATIONS
90-826883R2 JUNE 1998 Page 1A-3
Master Specifications
GEAR
HOUSING
Forward - Neutral - Reverse
Gear Ratio
Gearcase Capacity
Lubricant Type
Forward Gear - No. of Teeth-Type
Pinion Gear - No. of Teeth-Type
Pinion
Foreword Gear Backlash
Reverse Gear Backlash
Water Pressure @ RPM
Water Pressure With 120° Thermostat
Full Shift
2.25:1
8.8 fl.oz. (260 ml)
Quicksilver Gear Lube Premium
Blend
27
12
Not Adjustable
Not Adjustable
Not Adjustable
2-7 PSI @ 2000 RPM
0-6 PSI (SPORADIC) 2000 RPM
MID
SECTION
Transom Height - Short Shaft
- Long Shaft
15 in. (38 cm)
20 in. (51 cm)
FUEL
SYSTEM
Fuel Pump Type
Recommended Gasoline
Fuel Tank Capacity
Operating Fuel/Oil Ratio
Integral
Automotive Unleaded
with a Minimum Pump Posted
Octane Rating of 87
6.6 U.S. Gallons
50:1
OIL Recommended Oil (Pre-Mix @ 50:1) NMMA TC-W II or TC-W III
2-Cycle Outboard Oil
STARTING
SYSTEM
Manual Start
Rope Length
Electric Start
Ampere Draw (cranking)
Recoil
66 in. (1676 mm)
12 Volt
55 amperes
CHARGING
SYSTEM
Alternator Output
BLACK Stator - 2 Magnet Flywheel
(8 Pole)(4 Pulses)
RED Stator - 4 Magnet Flywheel
(10 Pole)(5 Pulses)
4 Amp. (48 Watt)
@ 6000 RPM
6 amp (72 Watt)
@ 6000 RPM
BATTERY Battery Rating 465 Marine Cranking Amps (MCA)
or 350 Cold Cranking Amps (CCA)
