Mercury 15XD User Manual

BATTERY CHARGING AND STARTING SYSTEMS
90-826883R2 JUNE 1998 Page 2B-3
Electric Start Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 RECTIFIER
2 2 SCREW (#10-16x5/8 IN.) Drive Tight
3 2 NUT (#10-32 Brass) 25 2.8
4 1 NUT (#10-32 Brass) 25 2.8
5 1 CABLE ASSEMBLY (Red)
6 1 STARTER SOLENOID ASSEMBLY
7 2 BUSHING
8 2 GROMMET
9 1 WIRE ASSEMBLY--yellow
10 2 SCREW (M6x1x25 hex head cap) 40 4.5
11 2 NUT (#8-32 Brass) 25 2.8
12 1 NUT (1/4-20) 30 3.4
13 1 INSULATOR--solenoid
14 1 NUT (1/4-20) 30 3.4
15 1 RETAINER--harness connector
16 1 J-CLIP
17 1 SCREW (M6x30 hex head cap) 140 12.0 15.8
18 1 WIRING HARNESS ASSEMBLY--engine
19 1 FUSE
20 1 STARTER MOTOR ASSEMBLY
21 1 THRU BOLT
22 1 END CAP (W/BRUSHES)
23 1 ARMATURE
24 1 DRIVE CAP
25 1 DRIVE
26 1 DRIVE KIT
27 2 SCREW (M8x1.25x55 hex washer) 220 18.0 24.8
28 1 CLIP
29 1 START SWITCH ASSEMBLY
30 1 HOUSING--switch
31 1 BATTERY WIRE ASSEMBLY--black
32 1 BATTERY WIRE ASSEMBLY--red
