22 Installation
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual logiJET T4-2 /T6-2 /RFID Edition 2.2
Fig. 2.4.c Printer opened
Lower cover
Printhead
pressure lever
Cover
Display
and
Control panel
Label
supply
guide
Label roll
bar
Printer
mechanism
