Miller OptX 2kW - Figure 6 Unit Locked on First Power up

To Next Page

To Previous Page

Safety and Compliance Information

OM-296747A | 4/15/24

▼Figure 6. Unit Locked on First Power Up

Webpage interface is locked

2. Press and hold both mode

buttons until mode display

starts flashing then release

1. Turn Laser Power knob to set

activation code

Unit is Locked
