Delivery and Transport
76
OM-296747A | 4/15/24
▼Figure 13. Domestic Shipments - Collapsible Crate
4.3 Transport to Installation Location
If the installation site is a long distance away, carefully place the umbilical on top
of the laser welder.
Using 2 people, pick up the device and load it onto a wheeled cart that is able to
support the weight of the device and accessories.
Transport the laser welder to the installation site.
NOTICE
Umbilical cable handling
Severe laser damage will occur if optical fiber cable, routed through the umbilical,
is mishandled (extreme bending, pulling or impact).
Do not bend the yellow optical fiber cable to a radius less than 50 mm minimum
bending radius.
Do not apply excessive load or impact to the fiber cable.
NEVER move or lift the unit by pulling or dragging on the umbilical cabling.
NOTICE
Avoid damage during transport
Always transport the laser welder in the upright position.
CAUTION
Avoid injury due to heavy weight - 72 kg (160 lb)
Physical injuries are possible when attempting to carry the unit alone.
Always handle the welding unit with 2 persons.
Manual handling only for limited time/distance.
No manual handling by persons with impaired physical performance.
Use material handling gear for long distance transport.
