Miller OptX 2kW - Unpacking from Shipping Container

Delivery and Transport
75
OM-296747A | 4/15/24
4.2 Unpacking from Shipping Container
Refer to Figure 13 [▶ 76] and Figure [▶ 76] for an illustration of this procedure.
1. Use pallet jack to move crate to unpacking location. Crate must be placed on
a stable surface. Remove the outer plastic wrap.
2. Remove the top lid and top foam insert.
3. The fiber umbilical will be looped and tie wrapped. The laser torch will also be
wrapped. Using a cutting tool remove the tie wraps securing the fiber to the
second insert.
4. Carefully place the umbilical and torch on top of the unit.
5. Remove the crate side panels. To remove unit from crate, pick it up using the
two handles at the top of the unit. Miller strongly recommends for two people
to lift the unit at all times. Be careful when handling the umbilical and torch.
6. A comprehensive packing list is included with the system documentation.
Check all items in the crate against this list.
7. Retain all packaging for future transportation or storage needs.
IMPORTANT
Miler recommends the following when unpacking the unit:
 Only work with suitable tools and aids
 Follow all steps to ensure safe unpacking of the products
 Always wear protective clothing
NOTICE
Umbilical cable handling
Severe laser damage will occur if optical fiber cable, routed through the umbilical,
is mishandled (extreme bending, pulling or impact).
 Do not bend the yellow optical fiber cable to a radius less than 50 mm minimum
bending radius.
 Do not apply excessive load or impact to the fiber cable.
 NEVER move or lift the unit by pulling or dragging on the umbilical cabling.
CAUTION
Avoid injury due to heavy weight - 72 kg (160 lb)
Physical injuries are possible when attempting to carry the unit alone.
 Always handle the welding unit with 2 persons.
 Manual handling only for limited time/distance.
 No manual handling by persons with impaired physical performance.
 Use material handling gear for long distance transport.
IMPORTANT
 Contact Miller immediately if any of the items are missing or if any damage to
the unit is evident. If any damage to the unit is evident or suspected, do not
attempt to install or operate the laser device in any case.
