Miller OptX 2kW - Table 24 Program Mode Button Functions

Operating Front Panel Controls
95
OM-296747A | 4/15/24
• Preset Programs are pre-programmed recipes from the factory. The program
identification number will be a letter followed by a number. (e.g. A0, A1, A2, C0, C1,
C2, etc).
• The Preset Program letter options can be: A, C, E, F, H, J, L, P, U, and Y.
▼Table 24. Program Mode Button Functions
Mode Button
Functions
Description
Select Program Recipe Pushing the Program Mode Up Button (right arrow) will
increase the Program Number by 1. Once it reaches 25
it will start back at 0, 1, 2, etc.
Pushing the Program Mode Down Button (left arrow)
will decrease the program Number by 1. Once it reaches
0 then it will go back to 25, 24, 23, etc.
To jump between program modes (User 0 to Preset A,
C, E etc), press and hold the Up Button for
2 seconds (or
Down Button if decreasing).
Once in the Preset Mode, push the Up or Down button
once to increment through the recipes for that Preset
mode (e.g. A0, A1, A2, etc).
Save Program Recipe For the selected program number, it will overwrite the
values according to the present values displayed for
Laser Power, Wobble Frequency and Wobble Length.To
save recipe that was created:
1. Press and hold both
the Mode Up and Down
buttons simultaneously for 3 seconds.
2. Once the display stops blinking it is confirmation
for the user that the program was saved
Reset Single
Existing Recipe
This will reset the selected program back to the factory
default.
1. Press and hold both
the Mode Up and Down
buttons simultaneously for 6 seconds.
2. Once the display starts blinking faster it is reset.
Reset All
Program Recipes
This will restore all program recipes back to the factory
default. This function can also be done from the web
page interface.
1. Press and hold both
the Mode Up and Down
buttons simultaneously for greater than 15
seconds.
2. Once the display starts blinking extremely fast it is
factory reset.
