Revision:1.0(2023-01-12)
133
44..33..22..44 Checking the ECG Function
Procedure Acceptance criteria
After confirming that the system has the
optional ECG function, set ECG to On.
ECG is activated. ECG waveforms and a heart
mark are displayed, and the respiratory
waveform is displayed on the upper right of
the screen.
Speed, ECG Gain, Position, Invert, and
other parameters can be adjusted in real time.
ECG physiological signals are played back
properly.
44..33..22..55 Checking the I/O Port
Procedure Acceptance criteria
Check each main I/O port.
• Network port
• HDMI port
• Other USB ports
• The network connection and
communication are normal.
• Through the HDMI port, the external
display can display information normally.
• USB storage and read/write are normal.
4.4 Function Check
4.4.1 Check Process
44..44..11..11 Check Process
This section lists the system check items when functions are complete and details key
items. If a software function is not configured, skip the corresponding check item.
Diagnostic Ultrasound System
Service Manual
4 Function and Performance
Check
