Revision:1.0(2023-01-12)
41
Type Model
Color video digital printer SONY UP-D25MD
Footswitch
971-SWNOM (wired, two keys)
971-SWNOM (wired, three keys)
2.2 Specifications
2.2.1 Physical Specifications
• Dimensions (folded state): (518±10) mm x (569±10) mm x (1303±10) mm
• Weight: 60±5 kg (excluding any available hardware accessories, peripherals, and probes)
2.2.2 Electrical Specifications
• Power supply voltage: 100-240 V~
• Power supply frequency: 50/60 Hz
• AC input current: 6.4-3.2 A; charging pile: 4.2-1.9 A
• Battery of the main unit: 14.4 V DC
2.2.3 Environmental Specifications
• Operating environment
– Ambient temperature: 0°C to 40°C
– Relative humidity: 20% to 85% (no condensation)
– Atmospheric pressure: 700 hPa to 1060 hPa
• Storage and transportation environment
– Ambient temperature: -20℃ to 55℃
– Relative humidity: 20% to 95% (no condensation)
– Atmospheric pressure: 700 hPa to 1060 hPa
2.2.4 Display Specifications
• Display: 21.5 or 23.8 inches
Diagnostic Ultrasound System
Service Manual
2 Product Knowledge
