Phillips pan-head screws that connect the Back Housing for Upper Column and push down the
Back Housing for Upper Column, so as to take off the Back Housing for Upper Column.
1 Three screw hole identification stickers and screws
2 Back Housing for Upper Column
7.28.3 Commissioning and Verification
None
7.29 Front Cover for Lower Column (FRU)
7.29.1 General Information
FRU Code
FRU Name Lower-Level FRU
Code
Lower-Level FRU
Name
115-083595-00 Front Cover of the
Lower Column (FRU)
7.29.2 Disassembly and Assembly
Precautions
Diagnostic Ultrasound System
Service Manual
7 FRU Replacement
