Revision:1.0(2023-01-12)
141
44..44..22..33 Checking the Cine Mode
Procedure Acceptance criteria
Tap the
icon to freeze the image.
The system enters the manual review state
automatically. (Prerequisite: Set Status after
Freeze to Cine.)
The system enters the cine review state.
Tap the
playback icon below the
image area.
Perform cine review manually.
Move the cursor to the start position (or image
frame) for review and tap the Play button on
the touch screen.
Set the start position for auto review.
Move the cursor to the end position (or image
frame) for review and tap the Play button on
the touch screen.
Set the end position for auto review.
Tap the
play button
Cine review is performed according to the
specified start and end positions.
Press Freeze again to unfreeze the image
.
The image is unfrozen. The system returns to
the scanning state and exits cine review.
Diagnostic Ultrasound System
Service Manual
4 Function and Performance
Check
