7.19.3 Commissioning and Verification
None
7.20 Main unit back cover
7.20.1 General Information
FRU Code
FRU Name Lower-Level FRU
Code
Lower-Level FRU
Name
115-084171-00 Main Unit Back Cover
7.20.2 Disassembly and Assembly
Precautions
When removing the main unit back cover (sy), do not pull apart the on/off button signal cable.
Tools Required
Crosshead screwdriver (M3)
Fixtures Required
Diagnostic Ultrasound System
Service Manual
7 FRU Replacement
