Mindray uMEC15 - Changing IBP Settings; Changing a Pressure for Monitoring

14-5
14.6 Changing IBP Settings
14.6.1 Changing a Pressure for Monitoring
1. Select the pressure you want to change to enter its setup menu. In the menu, there is a
figure showing the current IBP measurement connector.
2. Select [Label] and then select your desired label from the list. The already displayed
labels cannot be selected.
Label Description Label Description
PA Pulmonary artery pressure CVP Central venous pressure
Ao Aortic pressure LAP Left atrial pressure
UAP Umbilical arterial pressure RAP Right atrial pressure
BAP Brachial arterial pressure ICP Intracranial pressure
FAP Femoral arterial pressure UVP Umbilical venous pressure
Art Arterial blood pressure LV Left ventricular pressure
P1 to P4 Non-specific pressure label
