A-3
When the monitor is in use,
less than 11 hours to 90%
less than 12 hours to 100%
Shutdown delay at least 5 min (after a low battery alarm first occurs)
A.3 Physical Specifications
Model Size Weight Remark
uMEC15 405×165×305 mm 5.0 kg Standard configuration,
standard battery, without
accessoriesˈrecorder,
and other modules
uMEC12 345×160×255 mm 4.0 kg
uMEC10 315×155×220 mm 3.5 kg
A.4 Hardware Specifications
A.4.1 Display
Host display
Model Screen Size (diagonal) Screen type Resolution
uMEC15 15 inches
color LED
backlight LCD
at least 1024 × 768 pixels
uMEC12 12.1 inches
at least 800×600 pixels
uMEC10 10.4 inches
External display
Screen type Medical-grade LED backlight LCD
A.4.2 Recorder
Method Thermal dot array
Paper width 50 mm±1 mm
Paper speed 12.5 mm/s, 25 mm/s, 50 mm/s with accuracy within ±5%
Number of waveform channels Maximum 3
