A-5
PACE rejection/enhancement
Pace enhancement
Signal amplitude: Voh2.5V
Pulse width: 10ms±5%
Signal rising and falling time: 100μs
Nurse Call Signal
Amplitude
High level: 3.5 to 5 V, providing a maximum of 10 mA output
current;
Low level: < 0.5 V, receiving a maximum of 5 mA input
current.
Rising and falling time 1 ms
Defib Sync Pulse
Output impedance 100 
Max time delay 35 ms (R-wave peak to leading edge of pulse)
Amplitude
High level: 3.5 to 5 V, providing a maximum of 10 mA output
current;
Low level: < 0.5 V, receiving a maximum of 5 mA input
current.
Pulse width 100 ms ±10%
Rising and falling time 1 ms
Alarm output (Network connector)
Alarm delay time from the
patient monitor to remote
equipment
The alarm delay time from the patient monitor to remote
equipment is 2 seconds, measured at the monitor’s signal
output connector.
A.5 Data Storage
Trends
Trends: 120 hours, at 1 min resolution
Mid-length trends: 4 hours, at 5 s resolution
Long-trends: 1200 hours, at 10 min resolution
Parameter alarms
1800 physiological alarms and manual events and related
parameter waveforms.
Arrh. events 128 arrhythmia events and relate waveforms and parameters.
NIBP measurements 1600 sets
Full-disclosure waveforms
48 hours at maximum. The specific storage time depends on
the waveforms stored and the number of stored waveforms.
