6-2
 You can switch on or off the connected parameter modules in the [Parameters Switch]
window. If a parameter module is switched off, parameter values and waveforms will
not display on the screen.
6.2 Viewing Minitrends
6.2.1 Having a Split-Screen View of Minitrends
You can split the normal screen so that one part of the screen, on the left hand side,
continuously shows graphic minitrends beside waveforms as shown in the figure below.
To have a split-screen view of minitrends, you can:
 Select [Minitrends] QuickKey, or
 Select [Screens] QuickKey[Choose Screen][Minitrends Screen]
, or
 Select [Main Menu][Screen Setup >>][Screen Layout >>][Choose
Screen][Minitrends Screen]
.
Minitrend View
