2. CNC Monitor Screen
2.5 Program
I - 137
[Setting the program operation start position]
After setting a program for memory operation, the start block can be designated if you want to execute from
the midway block. The operation start position in normal word editing is set at the head of the program. To
change the start position, move the cursor to the head of the block to be started and press [INPUT].
(1) Move the cursor at the head of the block to
be started.
[↓][↑]
[BACK][NEXT]
(2) Press [INPUT].
The message "SEARCH COMPLETE"
appears and the operation is enabled from
the designated block.
CAUTION
If an operation start position is set in the halfway of the blocks and the program is started, the
program before the start position is set is not executed. If there is a coordinate system shift
command, or M, S, T and B commands before the block set as the starting position, execute the
necessary command with MDI etc. There is a danger of interference with the machine if the
operation is started from the block set as a starting position without executing these operations.
The head of the program will be searched if [INPUT] is pressed when the cursor is placed at other
than the head of the block. The program will be displayed from the head of the program.
