2. CNC Monitor Screen
2.5 Program
I - 136
[B.G END]
The "B.G END" menu is used to quit editing after executing the background editing.
If a running program is displayed on the EDIT screen, changeover to the running program will not occur
unless the [B.G END] menu is pressed and the background editing is canceled.
(The button does not have to be pressed even when quitting the background editing if the program in
operation is not displayed on EDIT screen.)
[Comment setting]
An outline of the machining program functions, specifications, applications, etc., can be set as a comment.。
(1) Press the menu [COMMENT].
The setting area for "COMMENT" will be
displayed.
O( ) COMMENT ( )
COMMENT
(2) Set the program No. that the comment to be
set.
(Example)
O( 100) COMMENT ( ABC)
O( 100) COMMENT ( ABC )
COMMENT
(3) Press [INPUT].
(a) Set the comment for the designated
program No.
But if the designated program No. is not
displayed on the screen, that program's
screen is displayed. Press [INPUT] again.
(Note 1) A program will be deleted if the program No. is entered and [C.B] is pressed when the setting
area is displayed.
To Next Page
