2. CNC Monitor Screen
2.6 Data In/Out
I - 146
(1) To erase one machining program
To erase a specified machining program from the machining programs registered in memory, perform
the following:
Set the data type and program
number of the machining program
to be erased.
(Example)
To erase machining program O111
# ( 1
)
DATA ( 1
1 1 )
Press the [INPUT] key.
1) Program erase is started and the
message ERASE EXECUTION is
displayed in the message field.
Usually program erasure is
terminated in a moment.
2) When the erase is complete, the
message ERASE COMPLETE is
displayed in the message field and
the data setting area becomes blank.
PROGRAM FILE before erase execution PROGRAM FILE after erase execution
Program O1001 for which the erase function is
executed disappears from the PROGRAM FILE screen.
The new values are displayed in PROGRAM ENTRY,
CHARACTER, and REMAIN.
111
111
To Next Page
