2. CNC Monitor Screen
2.7 Diagnosis
I - 202
# Item Details
Setting
range
35 ADDRESS Not used.
-
36 DATA Not used.
-
37 DATA MASK Not used. -
100 P.ON START
Sampling starts automatically immediately after NC’s power is turned ON.
(Note) When “1” is set, sampling starts every time the power is turned
ON until “0” is set again.
0,1
111
to
118
SIZE Not used. -
121
to
128
SHIFT
Designate the number of right-shifts for each channel, which will be
executed on a sampling data when outputting the sampling data.
(Note 1)
Shift is executed for the value after converting the output unit.
(Note 2)
Sign extension is executed when shifting.
0 to 63
131
to
138
MASK
Designate a mask applied to the sampling data (execute AND) for each
channel when outputting the sampling data. However, the mask is not
applied if 0(0x0000000000000000) is set.
(Note 1) Set “1” to the BIT to remain in the mask.
(Note 2) Mask is applied to the data after shifting.
(Note 3) On the screen, the data is displayed separately in higher (H) 32
bit and lower (L) 32bit although the 64 bit ( ) are input
continuously to the setting area to apply the mask.
0x00000000
00000000
to
0xFFFFFFFF
FFFFFFFF
141
to
148
TYPE
Designate the data type (with/without sign, notation system of base n) for
each channel when outputting the sampling data.
S: Decimal number with sign
U: Decimal number without sign
H: Hexadecimal number
0 (Blank): Handled in the same way as “S” is set.
(Note 1) This is invalid if “#6 OUTPUT FORM” is set to “1” (exclusive
type for synchronous tapping tool).
S,U,H,0
To Next Page
