Mitsubishi C70 User Manual

2. CNC Monitor Screen
2.1 Setting and Display Unit Operation
I - 11
(1) Select a function screen
[MONITOR] [DIAGN IN/OUT] [TOOL PARAM] [EDIT MDI]
Press the function selection key
corresponding to the function screen to be
displayed.
(Example) Press the [MONITOR] key.
1) The previously displayed menu screen is displayed in
the data display area.
2) The first display screen after power is turned on is the
screen on the first menu.
If the same function selection key is
pressed again, a return is made to the first
page screen of the first menu.
(Example) Press the [MONITOR] key again.
