Appendix 6. Operation Messages on Setting Display Unit
Appendix 6.1 Operation Errors
IV - 24
Error No. Error message Details
E04 DEV. NOT READY
×
• The input/output u/nit power is not ON.
• The cable is disconnected.
• Setting of the transfer speed (baud rate) does not agree.
E05 NOT
ACCEPTABLE
×
• The PLC timer cannot be set from the screen when the
program is valid. (When machine parameter bit selection #6449
bit 1 is set to 1.)
• The PLC counter cannot be set from the screen when the
program is valid. (When machine parameter bit selection #6449
bit 0 is set to 1.)
• The tool registration data setting is prohibited.
• Setting from the tool life management screen is prohibited.
• Absolute position setting screen’s "#1 ORIGIN" and "#2 ZERO"
cannot be set when "#0 INIT SET" is invalid.
• The INPUT key was pressed to perform search for the program
that is in background edit status on the word edit screen.
• The menu keys (Replace and Insert) on the word edit screen
were manipulated when a running program is displayed
(PDISP signal: ON).
• An attempt was made to set MDI data in an MDI setting lock
state (the MDI setting lock parameter is specified with 0 and a
non-MDI mode is valid).
• Language data in display selection status was entered.
Change the display selection status once before entering the
data. (#1043 lang)
• When the manual value command protection (#1228 aux12
/bit7) function is valid, the manual command operation (M, S,
and T keys) is performed in POSITION screen.
E06 NO SPEC
×
• The menu key for a function not in the specifications was
pressed.
• A parameter not in the specifications was set.
• A language that was not added as an option was selected.
(#1043 lang)
E07 RESET END
Δ
• The input/output operations were forcibly stopped by reset‚ etc.
(including EMG).
E08 PHYSICAL ERR
×
• The input/output parameter setting or input/output unit side
setting was incorrect.
E09 TIME OUT
×
• The input/output unit parameter "TIME-OUT TIME" setting was
too short.
• There is no EOB code in the machining program.
To Next Page
