2. CNC Monitor Screen
2.1 Setting and Display Unit Operation
I - 16
5) Data in parentheses where the cursor exists is erased by pressing the [C.B CAN] key.
Display is made in the setting area as
shown in the right.
# ( 10) DATA ( 12.34 5
)
If you press the [C.B CAN] key,
# ( 10) DATA (
)
6) Data in all parentheses in the setting area is erased by pressing [SHIFT] [C.B CAN] .
Display is made in the setting area as
shown in the right.
# ( 10) DATA ( 12.34 5
)
If you press [SHIFT][C.B CAN] ,
# ( ) DATA (
)
7) The cursor in parentheses is moved one column to the left or right by pressing the [←] or [→] key
desired character of data entered by using the data keys can be corrected.
Display is made in the setting area as
shown in the right.
# ( 10) DATA ( 12.34 5
)
If you make successive four strokes
of the [←] key,
# ( 10) DATA ( 1 2
.345)
If you press [3] ,
# ( 10) DATA ( 13 .
345)
2 is corrected to 3 and the cursor is moved one column to the right.
If you press the [→] key,
# ( 10) DATA ( 13.3
45)
The cursor is only moved one column to the right.
If you press [0] [0] [0] ,
# ( 10) DATA ( 13.00 0
)
The character at the cursor position is rewritten and the cursor is also moved one column to the
right. Data is corrected in sequence.
(Note 1) If [→] is pressed when the cursor exists in the right end within one parentheses, the
cursor is moved to the right end within the following parenthesis part; if [←] is pressed
when the cursor exists in the left end within one parentheses, the cursor is moved to the
right end within the preceding parentheses.
