2. CNC Monitor Screen
2.1 Setting and Display Unit Operation
I - 17
8) When the [→|] keys are pressed, the cursor is moved to the right end within the following
parentheses.
# ( 12 ) DATA ( 23 4
)
If you press the [→|] key, the cursor is
moved to the right end within the following
parentheses.
# ( 12 3
) DATA ( 3 4 )
If you press the [|←] key, the cursor is
moved to the right end within the preceding
parentheses.
(3) Miscellaneous information
1) Data can also be set by other special methods. See the appropriate items. (For example, manual
numeric command setting is performed by the reverse display setting method.)
2) If an invalid key is pressed when data is set within parentheses, a "setting error" will occur at input
time and the data will not be accepted. Again set correct data from the beginning.
3
2
