A-73
FX Series PLC User's Manual - Data Communication Edition
Common Items
5 Abbreviations, Generic Names and Terms Used in This Manual
4.2 Introduction of Related Manuals
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter
Communication
F
Non-Protocol
Communication
(RS/RS2 Instruction)
G
Non-Protocol
Communication
(FX
2N
-232IF)
H
Programming
Communication
I
Remote
Maintenance
Apx.
Discontinued
models
3. Extension equipment
4. Networks
Special adapters
Special adapter connection
conversion adapter or
connection conversion
adapter
Generic name of CNVADP
CNVADP FX
3G-CNV-ADP
Abbreviation/
generic name
Name
Extension equipment
Extension equipment
Generic name of extension blocks, powered extension units, special function blocks
and special function units
Special function unit Generic name of special function units
Special function block Generic name of special function block
232IF Generic name of FX
2N-232IF
Abbreviation/
generic name
Name
Open field networks CC-Link and CC-Link/LT
CC-Link equipment
Generic name of CC-Link master station and CC-Link remote device stations and CC-
Link intelligent device stations
CC-Link master (station) Generic name of CC-Link master station with model name FX
2N-16CCL-M
CC-Link remote station Generic name of remote I/O stations and remote device stations
CC-Link intelligent device
station
Generic name of CC-Link intelligent device station with model name FX
3U-64CCL
CC-Link/LT equipment
Generic name of CC-Link/LT master station, CC-Link/LT remote I/O stations, power
supply adapters, and dedicated power supplies
CC-Link/LT master Generic name of built-in type CC-Link/LT master and (additional) CC-Link/LT master
Built-in type CC-Link/LT
master
Generic name of built-in type CC-Link/LT master built in to the FX
3UC-32MT-LT(-2)
(Additional) CC-Link/LT
master
Generic name of CC-Link/LT master station with model name FX
2N-64CL-M
Power supply adapter Generic name of units connecting the power supply to the CC-Link/LT system
Dedicated power supply Generic name of power supplies connected to the CC-Link/LT system
AS-i system
AS-i master Generic name of AS-i system master station with model name FX
2N-32ASI-M
MESEC I/O LINK
MELSEC I/O LINK master Generic name of MELSEC I/O LINK master station with model name FX
2N-16LNK-M
Abbreviation/
generic name
Name
