FX Series PLC User's Manual - Data Communication Edition
Common Items
1 Introduction
1.2 Outline and Features of Communication Types
3) When the master station is an FX PLC
2. Applicable PLCs
:Applicable (If applicable versions of main units are limited, they are described inside ( ).)
—:Not applicable
*1. Does not support the access function to the FX Series PLC main unit via another station QCPU (Q
mode).
*2. Supports the access function to FX Series PLC main units via another station QCPU (Q mode) using
GX Developer Ver. 8.72A or later.
3. Communication targets
Equipment operating in accordance with the CC-Link standard
4. Function
Master station allows connection of remote device station, remote I/O station (inverters, AC servos, sensors,
solenoid valves, etc.) supporting the CC-Link network to achieve data link.
FX PLCs are classified as master stations, remote device stations or intelligent device stations.
5. Applications
Decentralized or centralized control of the line, reception and sending of information from/to the host network,
etc.
6. Detailed information on CC-Link
For details on CC-Link and connectable equipment, refer to the CC-Link Partner Association's homepage or
catalogues (issued by the CC-Link Partner Association).
→ CC-Link Partner Association's homepage: http://www.cc-link.org/
PLC FX2(FX),FX2C FX0N FX1S FX1N FX1NC FX2N,FX2NC FX3G FX3U,FX3UC
Master station
(FX
2N-16CCL-
M)
———
(Ver.1.10 or later)
(Ver.2.20 or later)
Remote device
station
(FX
2N-32CCL)
— —
Intelligent
device station
(FX
3U-64CCL)
——————
*1
*2
(Ver.2.20
or later)
Master
station
Terminal resistor
FXCPU
FXCPU
Remote
device
station
Remote I/O
for CC-Link
Inverter,
AC servo, etc.
Sensor, solenoid valve,
etc.
Terminal resistor
• Number of connectable units
• Total extension distance
: Remote I/O station
: Remote device station
: 1200 m (3937’ 0")
7 maximum
8 maximum
To Next Page
