E-76

FX Series PLC User's Manual - Data Communication Edition

Inverter Communication

8 Practical Program Examples (for FX2N and FX2NC PLCs)

8.1 Practical Example 1

3. Controlling operations of an inverter

X000

SET M15

Operation stop

command input

Operation

stop

Operation stop is reset

by input X001 or X002

b1 of H0FA is set to ON

H0FA is set to "00H"

RST M15

Operation

stop

Forward rotation

command

Forward

rotation

command

input

b2 of H0FA is set to ON

Operation command is written

M27 to M20

→

H0FA

X002

X001

X002

Reverse rotation

command input

X000

Operation stop

command input

M21

M15

Operation

stop

X001 X002

X001

Forward

rotation

command

input

Reverse rotation

command input

Reverse

rotation

command

input

Forward rotation

command input

M8000

RUN monitor

M22

Reverse rotation

command

H0FA K2M20

FNC180

EXTR

K11 K0
