H-38
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
6 Connection Setting for Personal Computer
6.1 Connection Setting (GX Developer)
3 Setting the communication port and transmission speed
Set these items according to the connection status.
When "USB(GOT transparent) or USB(standard built-in port)" is selected in step 2 above, it is not
necessary to set "COM port" and "Transmission speed".
COM port: Select the communication port in the personal computer to be used (among
COM1 to COM63).
Transmission speed:Set the communication speed with the FX PLC.
The applicable transmission speed varies depending on each FX PLC. Refer
to the table below.
*1. For achieving communication at 38.4 or 115.2 kbps in an FX3G PLC, the FX-232AWC-H is required.
*2. For achieving communication at 38.4, 57.6, or 115.2 kbps in an FX
3U/FX3UC PLC, the FX-232AWC-H,
FX-USB-AW, or FX
3U-USB-BD is required.
Communication
speed
FX0,
FX0S
FX0N FX1
FX2(FX),
FX
2C
FX1S
FX1N,
FX
1NC
FX2N,
FX
2NC
FX3G
*1
FX3U,
FX3UC
*2
9.6 kbps
19.2 kbps—————
38.4 kbps———————
57.6 kbps———————
115.2 kbps — — — — — — —
To Next Page
