Mitsubishi FX3U-20SSC-H User Manual

7 Before Starting Positioning Operation
118
FX3U-20SSC-H Positioning Block User's Manual
7.9 Other functions
7.9.9 Current address change function
With this function, the current address of a stopped axis changes arbitrarily.
Write the desired value to the current address (user) to change, followed by the current address (pulse)
update.
→ For parameters, control data and monitor data, refer to Chapter 11
Note
The current address does not change in the following states.
• READY/BUSY in the status information is OFF (0).
• Interruption due to a STOP command occurs and the operation is waiting for the remaining distance.
7.9.10 Zero return interlock function
This function disables the start command before mechanical return.
→ For the parameters, control data and monitor data, refer to Chapter 11
1. Applicable positioning operations
2. Setting items
When using the zero return interlock function, set to ON the "zero return interlock setting enabled/disabled"
bit.
Condition disabling the zero return interlock function
The zero return interlock function is disabled in the following cases:
• When the "zero return interlock setting enable/disabled" bit is set to "OFF"
• When the "zero return complete" flag is ON
BFM Number
Data type
X-axis Y-axis
Current address (user) BFM #1, #0 BFM #101, #100 Monitor data
Current address (pulse) BFM #3, #2 BFM #103, #102 Monitor data
READY/BUSY Status information BFM #28 b0 BFM #128 b0 Monitor data
Standby for remaining
travel distance at stop
Status information BFM #28 b7 BFM #128 b7 Monitor data
• Operations applicable to the zero return
interlock setting
• Operations inapplicable to the zero return
interlock setting
- 1-speed positioning operation
- Interrupt 1-speed constant quantity feed
- 2-speed positioning operation
- Interrupt 2-speed constant quantity feed
- Interrupt stop
- Multi-speed operation
- Linear interpolation
- Linear interpolation (interrupt stop)
- Table operation (individual)
- Table operation (simultaneous)
- Reciprocal movement instruction
(Ver. 1.10 or later)
- JOG operation
- Manual pulse generator operation
- Mechanical zero return
- Variable speed operation
BFM Number
Description
X-axis Y-axis
Zero return
interlock setting
enabled/disabled
Operation
parameter 2
BFM #14002
b2
BFM #14202
b2
Enables or disables the OPR interlock function.
1(ON): Enable
Disables the START command without zero return
completion. Enables the START command with zero
return completion (zero return completed: ON)
0(OFF): Disable
Zero return
complete
Status
information
BFM #28 b3 BFM #128 b3
Turns ON upon completion of mechanical zero return operation, or
when the current position is established by the absolute position
detection system.
Turns OFF at OFF-to-ON transition of a mechanical zero return
command, at power-off (reset), or when an absolute position is
lost during the absolute position detection system.
