Mitsubishi FX3U-20SSC-H User Manual

11 Buffer Memory (Parameters & Monitored Data)
11.3 Monitor Data
233
FX3U-20SSC-H Positioning Block User's Manual
11
Buffer Memory
12
Program Example
13
Diagnostics
A
List of Parameters and Data
B
Version Information
11.3.23 Motor speed [BFM #53, #52, BFM #153, #152]
The present rotation speed of the servo motor is stored.
11.3.24 Motor current value [BFM #54, BFM #154]
A ratio of the present value of the rated servo motor current is stored.
11.3.25 Servo amplifier software number [BFM #61 to #56, BFM #161 to #156]
The software number of the servo amplifier is stored.
Updated at control power on to the servo amplifier.
Note
The servo amplifier software number is stored in ASCII code as shown below.
Example: When the number is :
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #53, #52
BFM
#153, #152
The present rotation speed of the servo motor (×0.1 r/min) Decimal -
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #54 BFM #154 The value of the servo motor current (× 0.1%) Decimal -
BFM Number
Description Value Format Default
X-axis Y-axis
BFM
#61 to #56
BFM
#161 to #156
Servo amplifier software number ACSII code -
BFM Number Monitor Value ASCII Code Servo amplifier software number
BFM #56 H422D B -
BFM #57 H3533 5 3
BFM #58 H3257 2 W
BFM #59 H3030 0 0
BFM #60 H4120 A SPACE
BFM #61 H2030 SPACE 0
-B35W200
A0
-B35W200 A0
