11 Buffer Memory (Parameters & Monitored Data)
11.1 Positioning Parameters
210
FX3U-20SSC-H Positioning Block User's Manual
11.1.11 Zero return speed (High Speed) [BFM #14025, #14024, BFM #14225, #14224]
This parameter sets the mechanical zero return operation speed (high speed) [DOG, Stopper #1].
For details on the mechanical zero return, refer to Section 8.1
*1. Refer to the section shown below for details on the user units and converted pulse data.
Refer to Section 7.10
Note
Set the zero return speed (high speed) at or below the maximum speed.
When the zero return speed (high speed) exceeds the maximum speed, the 20SSC-H operates at the
maximum speed.
Speed change commands in positioning operation change the zero return speed (high speed) into a preset
value.
11.1.12 Zero return speed (Creep) [BFM #14027, #14026, BFM #14227, #14226]
This parameter sets the mechanical zero return operation speed (creep) [DOG, Stopper #1, #2].
For details on the mechanical zero return, refer to Section 8.1
*1. Refer to the section shown below for details on the user units and converted pulse data.
Refer to Section 7.10
Note
Set the zero return speed (creep) at or below the maximum speed and zero return speed (high speed).
When the zero return speed (creep) exceeds the maximum speed, the 20SSC-H operates at the maximum
speed.
Set the speed as slow as possible to achieve the best stop position accuracy.
11.1.13 Mechanical zero-point address [BFM #14029, #14028, BFM #14229, #14228]
This parameter sets the current value address at zero return operation completion.
After mechanical zero return completion, the 20SSC-H writes the current address to this parameter.
For details on the mechanical zero return, refer to Section 8.1
*1. Set a value within the range from 0 to the ring value during the ring operation.
*2. Refer to the section shown below for details on the user units and converted pulse data.
Refer to Section 7.10
BFM Number
Description Default
X-axis Y-axis
BFM
#14025,
#14024
BFM
#14225,
#14224
Setting range: 1 to 2,147,483,647 (user unit)
*1
Set the value within 1 to 50,000,000Hz in converted pulse data
*1
.
K4,000,000
BFM Number
Description Default
X-axis Y-axis
BFM
#14027,
#14026
BFM
#14227,
#14226
Setting range: 1 to 2,147,483,647 (user unit)
*1
Set the value within 1 to 50,000,000Hz in converted pulse data
*1
.
K100,000
BFM Number
Description Default
X-axis Y-axis
BFM
#14029,
#14028
BFM
#14229,
#14228
Setting range
*1
: -2,147,483,648 to 2,147,483,647 (user unit)
*2
Set the value within -2,147,483,648 to 2,147,483,647PLS in converted pulse data
*2
K0
