FX3U-20SSC-H Positioning Block User's Manual
10.3 Tables and BFM No. Allocation
Stores the table operation information to the 20SSC-H buffer memory. There are 2 BFM types, one for
operation by individual axis (X/Y axis) and the other for XY-axis simultaneous operation.
Note
• The save command (BFM #523 b2 to b4) writes and stores the BFM table information in the 20SSC-H flash
memory.
→ For a program example, refer to Subsection 7.1.9
• The default value for table information is "-1."
• The 20SSC-H stores the table number in execution in the executing table number (BFM #16, #116).
Caution for setting
Selecting the following patterns in the operation information requires two table rows.
• 2-speed Positioning operation
• Interrupt 2-speed constant quantity feed
Table No. Items
BFM No.
X-axis table
information
Y-axis table
information
XY-axis table
information
0
Position information
Position data x BFM #1001, #1000 - BFM #7001, #7000
Position data y - BFM #4001, #4000 BFM #7003, #7002
Speed information
Speed data f, fx BFM #1003, #1002 - BFM #7005, #7004
Speed data fy - BFM #4003, #4002 BFM #7007, #7006
Circle information
Center coordinate i,
radius r
- - BFM #7009, #7008
Center coordinate j - - BFM #7011, #7010
Operation information BFM #1004 BFM #4004 BFM #7012
m code information BFM #1005 BFM #4005 BFM #7013
:
299
Position information
Position data x BFM #3991, #3990 - BFM #12981, #12980
Position data y - BFM #6991, #6990 BFM #12983, #12982
Speed information
Speed data f, fx BFM #3993, #3992 - BFM #12985, #12984
Speed data fy - BFM #6993, #6992 BFM #12987, #12986
Circle information
Center coordinate i,
radius r
- - BFM #12989, #12988
Center coordinate j - - BFM #12991, #12990
Operation information BFM #3994 BFM #6994 BFM #12992
m code information BFM #3995 BFM #6995 BFM #12993
11 3000 1000
Table No.
One positioning operation is performed using
two table rows. (*1)
When only 1 table row is set, the next table row
(table No.11) is judged to be the 2nd speed of table
No.10 and the operation is performed using that
table information. (*2)
Position
information
Speed
information
m code
information
Operation
information
0 500 500 -17
10 5000 500 -17
3
-1
Operation
information
Table No.
Position
information
X-axis Y-axis X-axis Y-axis X-axis Y-axis
Speed
information
Circle
data
m code
information
0 5800 10000
1000
6000
1200
600
1200
5000 9 -1
10 500 500 9 -1
11 800 1000 3 -1
1
3000 5000
--
--
--
--
1500
1000 9 -1
1 3000 300 -17
In the case of X-axis, Y-axis table information
In the case of XY-axis table information
*1
*2
