10.2 How to Set Table Information
The 20SSC-H has 2 procedures to set table information, via FX Configurator-FP or by a sequence program.
Setting table information by sequence program
To set table information by a sequence program, write each setting to the 20SSC-H buffer memory with TO,
or move instructions (MOV, etc.) for direct specification.
For details on buffer memory assignments, refer to the following.
→ Refer to Section 10.3 and 11.5
Note
It is strongly recommended to set and store table information in the flash memory via FX Configurator-FP.
When table information is set by sequence program, a considerable amount of the sequence program and
devices are used, which makes the program complicated and increases the scan time.
Setting table information on FX Configurator-FP
Set value with the X-axis, Y-axis, XY-axis table information edit windows in FX Configurator-FP.
For details on operation with FX Configurator-FP, refer to the following manual.
→ FX Configurator-FP Operation Manual
• Operation method
1) Double-click "File name"→"Edit"→"X-axis table information", "Y-axis table information" or "XY-axis table
information" in the file data list.
2) The selected X-axis table information, Y-axis table information or XY-axis table information edit window is
displayed.
